IMAGE DYNAMICS IDQ12 V.4 D2 12" SUB DUAL 2-OHM 1500W MAX SUBWOOFER SPEAKER NEW
이미지 다이내믹스 IDQ12 V.4 D2 12인치 서브 듀얼 2-OHM 1500W 최대 서브우퍼 스피커 신제품
| 상품번호 | 130942396763 |
| 상태 | New |
| 거래유형 | 즉시구매 |
| 출고국 | 미국 (US) |
상품 설명
   Brand New!IDQ12 V.4 D2 - Image Dynamics 12" Dual 2-Ohm IDQ V.4 Series SubwooferRetail Price: |
| Features & Specifications: |
The Image Dynamics IDQ12V4-D2 is a premium 12-inch dual 2-ohm voice coil subwoofer from the acclaimed IDQ V4 series. Engineered for exceptional sound quality and versatility, it features a high-excursion design that delivers acoustically linear, distortion-free bass reproduction across all rated power levels. Built with multi-enclosure compatibility in mind, it performs beautifully in compact spaces and includes a field-replaceable cone assembly for quick, hassle-free maintenance.
Features
- High Excursion Design allows acoustically linear bass output at all rated power levels
- Parabolic Santoprene Surround ensures strict cone linearity and control
- Poly Mica Cone delivers strong, distortion-free bass while reproducing fine musical nuances
- Nomex Spider provides consistent control throughout the piston range and extends the life of the woofer
- Poly Carbonate Neck Joint handles raw power without mechanical failure while isolating heat from the BASV voice coil former away from the cone
- American Made Flat Wound Extended Voice Coil gives higher magnetic flux and over 1.813 inches of linear travel in the magnetic gap
- Extended Y-35 Motor Structure allows the voice coil to move freely without mechanical bottoming out
- Field Replaceable Cone Assembly can be changed in 10 minutes with 16 screws and alignment shims included in the recone kit
Specifications
- Speaker Size: 12 inches
- Voice Coil Configuration: Dual 2-Ohm (DVC)
- Power Handling: 375 Watts Recommended RMS / 750 Watts Max RMS
- Frequency Response: 35 - 500 Hz
- Sensitivity (SPL): 86 dB
- Xmax (Linear Travel): 14.5 mm
- Voice Coil Size: 2 inches
- Voice Coil Height: 38.3 mm (1.5 inches)
- Voice Coil Type / Former: BASV
- Voice Coil Wire Material: Aluminum
- Resonant Frequency (Fs): 34 Hz
- DC Resistance (Re): 1.4 Ohms
- Motor Structure Weight: 280 oz
- Net Weight: 20.3 lbs
- Driver Displacement: 0.10 cu ft
Thiele-Small Parameters
- SD: 510.72 sqCM
- Vas: 48.5667 L
- Cms: 122 um/N
- Mms: 170.6 g
- BLTM: 6.54
- Qms: 5.381
- Qes: 0.786
- Qts: 0.681
- No: 0.224%
- Voice Coil Inductance @ 1 kHz: 0.79 mH
Physical Dimensions
- Overall Outer Diameter: 12.46 inches
- Mounting Cutout Diameter: 10.937 inches
- Total Mounting Depth: 5.91 inches
- Magnet Depth: 2.52 inches
- Magnet Diameter: 5.52 inches
